Overview
iQ77 series is innovative versatile time clocks which combine a highly durable yet elegant casing with a variety of identification methods from bar code cards, magnetic stripe cards, RFID/proximity cards and/or fingerprints (shown).
Offering unparalleled performance on an embedded Linux platform with all the features a modern time and attendance reader should have including relay contacts for access control/external bell.
TCP/IP communication is standard and will ensure that data transmission between the terminal and PC is error free and with optional WiFi communication installation of the clock becomes easy.
The USB port can be used to transfer the data to and from the USB flash drive. iQ77 is an easy plug-in solution for existing time attendance software developers who have already integrated other market readers.
Main Features
- Color TFT screen with graphical interface for ease of use
- Rugged and highly accurate SOMAX optical sensor 500dpi
- No need to enter PINs
- Rugged 20-key keypad with four programmable function keys
- USB host port for easy data transfer to a USB flash drive
- Relay contacts for access control/external bell function
- Serial port can be used for communication with reader or for attaching a printer
- Optional WiFi connectivity allows for easy and hassle free installation over a wireless network
- Audio and Visual feedback for accepted and rejected swipes
- Multi-language firmware supports English, Spanish & French
- Included mounting plate is designed to fit standard US double gang box
- SDK available for OEM customers and software developers
Specifications
- Embedded Linux Operating System
- 10000 Cards Capacity
- 100000 Transactions Capacity
- 3000 one to many / 5000 one to one(Optional) Fingerprint Capacity
- Support Pin Code
- 3" color TFT screen LCD Display
- Built-in scheduler and relay contact
- Rugged 20 keys Keypad
- 4 Function keys
- Voice prompt (Support)
- Visual prompt LED (green/red)
- Number of Job / Dept codes (1)
- Support SMS message
- Ethernet (10/100M) / RS232/485 / USB-HOST
- Operating Temp 0-50șC
- Operating Humidity 20%-90%
- 12V DC, 1.5A Power Supply
- Dimensions L 6.5 in * W 5.5 in * D 1.8 in
- Weight 3lbs
Part Numbers
- iQ77F (Fingerprint)
- iQ77FP (Fingerprint /125 KHz generic Proximity reader)
- iQ77FH (Fingerprint / 125 KHz HID reader)
- iQ77FM (Fingerprint / 13.56 Mhz Mifare reader)
- iQ66P (125 KHz generic Proximity reader)
- iQ66H (125 KHz HID reader)
- iQ66M (13.56 Mhz Mifare reader)
- iQ55B (Barcode reader (3 of 9) or (2 of 5))
- iQ55G (Magnetic reader track II)
iQxx Series
Products
Let Us Help
Customer Support Phone
310-518-3250
800-889-9025
orders@i-rugged.com
Customer Support
310-834-0856
866-320-6666
support@i-rugged.com
Sales
310-518-3250
800-889-9025
sales@i-rugged.com
Knowledge Center
© Copyright iRugged Systems. 2011 | All Rights Reserved | Double Distilled by Jorando Kapello
www.i-rugged.com
Pinnacle is proud to be a distributor of the iRugged product range. Their locally designed and manufactured products are robust, rugged, built using only quality components and above all, extremely well priced for the local market, IQxx Series Choice of Barcode, Mag Stripe, Proximity or Fingerprint
| Join our mailing list |iRugged announces development partnership with HID
www.i-Rugged.com
iRugged systems specialses in the design, manufacture and distribution of biometric and NETWORK-based technologies
iQ77F / iQ77FP/H/M
iQ77FW /iQ77FP/H/M-W
iQ66P / iQ66M / iQ66H
iQ66PW / iQ66MW / iQ66HW
iQ55B / iQ55G
iQ55BW / iQ55GW
Product Packaging
- 1 Reader
- 1 12V DC, 1.5A Power Adapter
- 1 Ethernet Cable
- 1 USB Cable
- 1 Screw Driver
- 1 Set of Mounting Screws
- 1 Mounting Bracket
- 1 Mounting Paper
- 1 User Guide
Optional
- WiFi (W)
- POE (O)
- HID iClass cards (C)
